SPECIFICATIONS
Model: Legion 5 15AHP10 (83M0005DTA)
Processor: AMD Ryzen 7 260 with AMD Ryzen AI (3.8GHz up to 5.1GHz, 8C / 16T, 8MB L2 Cache / 16MB L3 Cache)
Chipset: AMD SoC Platform
CPU Series: Ryzen 7
AI Engine:
AMD Ryzen™ AI
• Performance: Up to 16 TOPS
• Total Processor Performance: Up to 38 TOPS
• NPU Performance: Up to 16 TOPS
Graphics: NVIDIA GeForce RTX 5060 (8GB GDDR7)
Display Screen: 15.1" 2560x1600 (WQXGA) 16:10, OLED, 165Hz, 500nits, Glossy, 100% DCI-P3, Dolby Vision®, DisplayHDR™ True Black 600
Main Memory: 16GB (1x 16GB) DDR5-5600 SO-DIMM
Memory Slot: 2x DDR5 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-5600 offering
Storage: 1TB SSD M.2 2242 PCIe 4.0x4 NVMe
Storage Slot: 2x M.2 2280 PCIe® 4.0 x4 slots
Optical Disk Drive: None
Web Camera:
• 5.0MP with E-shutter
• 2x, Array Microphone
Sound Technology: High Definition (HD) Audio, Realtek® ALC3287 codec
Audio Jack: 1x Headphone / microphone combo jack (3.5mm)
Speaker: Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
OS: Windows 11 Home
Special Feature: AI Chip: LA1
Network: 10/100/1000 LAN
Wireless: Wireless 802.11be (Wi-Fi 7)
Bluetooth: Bluetooth 5.4
Ports:
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 65-100W and DisplayPort™ 2.1*
1x USB-C® (USB4® 40Gbps), with DP 1.4
1x HDMI® 2.1, up to 8K/60Hz
*Supports Lenovo protocol for 140W charging but requires a unique Lenovo adapter for operation.
CardReader: None
Battery: Integrated 80Wh
Power Adapter: 245W Slim Tip (3-pin)
Dimension (cm) (W x L x H): 34.49 x 25.53 x 2.15 cm
Net Weight (kg): 1.90 kg
Package Dimension (cm) (W x L x H): 8.00 x 51.00 x 33.00 cm
Gross Weight (kg): 3.26 kg
Volume (cm³): 13,464.00 cm³
Material: Aluminium (Top), PC-ABS + 15% Talc (Bottom)
KeyboardType: ENG/TH, 6-row, multimedia Fn keys, numeric keypad, Copilot key
Backlit: 24-Zone RGB backlight
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP)
Finger Print: None
